¶ Related Resources
There are no related resources.
¶ Assembly
¶ CAD Files
¶ Specifications
| Attribute | Value |
|---|---|
| SKU | HDILC-B-O-20-F |
| Brand | Ooznest |
| Stock Type | New |
| Weight (g) | 6.32 |
| Profile Series | 20 Series |
| Material | Die Cast Zinc |
| Colour | Natural |
| Thread | M5 |
| Socket Size (mm) | 2.5 |
| Number Of Fixing Points | 2 |
| Number Of Ways | 2 |
| Insertion Type | End |
| Connecting Angle (°) | 90 |
| Orientation | Outside |
¶ What's Included
| Qty | Name |
|---|---|
| 2x | M5x6mm Cup Point Grub Screw (DIN 916, A2 Stainless Steel) |
| 1x | 20 Series T/V-Slot Heavy Duty Outside Butt Inner Link Connector |
¶ Additional Notes
There are no additional notes.
