¶ Specifications
| Attribute | Value |
|---|---|
| SKU | DIB-20-M5-25 |
| Brand | Ooznest |
| Stock Type | New |
| Weight (g) | 4.20 |
| Profile Series | 20 Series |
| Material | Carbon Steel |
| Surface Finish | Nickel Plated |
| Colour | Natural |
| Thread | M5 |
| Thread Pitch (mm) | 0.8 |
| Thread Length (mm) | 25 |
| Length (mm) | 25 |
| Insertion Type | Face |
| ESD Connection | Yes |
| Pull Out Loading Rating (N) | 684 |
¶ What's Included
| Qty | Name |
|---|---|
| 1x | M5x25mm 20 Series T/V-Slot Drop In Bolt (Nickel Plated) |
