¶ CAD Files
¶ Specifications
| Attribute | Value |
|---|---|
| SKU | TB-8-BA8 |
| Brand | Ooznest |
| Stock Type | New |
| Weight (g) | 9.00 |
| Inside Diameter (mm) | 8 |
| Outside Diameter (mm) | 18 |
| Thickness (mm) | 7 |
| Inside Diameter Tolerance (mm) | -0.007 - 0 |
| Outside Diameter Tolerance (mm) | -0.01 - 0 |
| Precision Class | P6 |
| Noise Class | V1 |
| Vibration Class | Z1 |
| Static Axial Load Rating (N) | 3798.78 |
| Dynamic Axial Load Rating (N) | 3189.37 |
| Maximum RPM Grease | 17000 |
| Maximum Temperature (°C) | 110 |
¶ What's Included
| Qty | Name |
|---|---|
| 1x | 8x19x7mm Thrust Bearing (BA8) |
¶ Additional Notes
There are no additional notes.
