¶ Specifications
| Attribute | Value |
|---|---|
| SKU | DUET-W-EA |
| Brand | Duet3D |
| Stock Type | New |
| Weight (g) | 220.00 |
| Version | Wifi |
| Voltage Rating (V) | 11 - 25 |
| Duet Family | 2 |
| Processor | Atmel ATSAM4E8E (ARM Cortex M4F) |
| Firmware | RepRapFirmware 2.0+ |
| Connectivity | Wifi (Integrated) |
| Stepper Driver Outputs | 5 |
| Stepper Driver Model | TMC2660 |
| Stepper Driver Rating (A) | 2.4 Peak (1.7 RMS) |
| High Current Outputs | 1 x 15A PWM, 2 x 6A PWM |
| Medium Current Outputs | 2 Always-on, 3 x PWM |
| Temperature Inputs | 2 x Daughter Board, 3 x Thermistor / 3 x PT1000 |
| Inputs/Outputs | 12 x Input / Output |
| Maximum Temperature (°C) | 70 |
¶ What's Included
| Qty | Name |
|---|---|
| 1x | Wifi External Antenna Duet 2 Controller |
¶ Notes
- Includes applicable connector pack
¶ Additional Notes
There are no additional notes.
